The Siemens HF222NR is a 60 Amp fused safety switch for compatible electrical disconnect applications. It has a 2-pole, 3-wire configuration, 240V AC / 250V DC ratings, a NEMA Type 3R enclosure, and quick-make, quick-break operation.
Condition: Brand new.
KEY FEATURES
• 60 AMP FUSED SAFETY SWITCH: Rated for 60 amps with a 2-pole, 3-wire configuration.
• 240V AC / 250V DC RATING: Specified for compatible systems requiring these voltage ratings.
• NEMA TYPE 3R ENCLOSURE: Designed for installations requiring a Type 3R enclosure.
• QUICK-MAKE, QUICK-BREAK OPERATION: Provides positive switching action when turning the switch on or off.
• WIRING GUTTERS: Top, bottom, and side gutters meet or exceed NEC wire-bending space requirements.
SPECIFICATIONS
• Brand: Siemens
• Model Number: HF222NR
• Product Type: Heavy-Duty Fused Safety Switch
• Current Rating: 60 Amp
• Number of Poles: 2-Pole
• Wiring Configuration: 3-Wire
• AC Voltage Rating: 240V AC
• DC Voltage Rating: 250V DC
• Fuse Type: Fused
• Enclosure Type: NEMA Type 3R
• Operating Mechanism: Quick-Make, Quick-Break
• Wiring Space: Top, Bottom, and Side Gutters
• Application: Electrical Disconnect Applications
